SAF-MD电源电涌保护器D系列

产品介绍:

该系列产品为新-代可插拔电涌保护器,标称放电电流更大,运行电压更高,适用于TN-C、TN- -ST和TT系统,响应时间快,电压保护水平更好。产品采用模块化设计,温控断路技术,内置过流熔断器和热感断路器,通过机械指示窗口显示工作状态; .该产品规格齐全、维护简单等诸多优点,可提供多种不同工作电压等级和雷电通流容量的产品.并可根据用户需要,定制生产。


This series of products is a new generation of pluggable surge protector with higher nominal discharge current and higher operating voltage. It is suitable for TN-C, TN-ST and TT systems with fast response time and better voltage protection level.The product is modular design, temperature control circuit technology, built -in over-current fuse and thermal circuit breakers, through the mechanical indication window shows the working status of the product specifications, maintenance and many other advantages, can provide a variety of dfferent vltage levels and Lightning flow capacity of the product, and according to user needs, custom production.


产品特点

1.可插拔模块设计,配置遥信接口, 远程告警;
2.劣化时自动脱扣,可视告警指示窗C绿色(正常)变成红色(故障)
3.漏电流小,响应时间快残压低。
4. 8/20 μs波形;
1. Pluggable module design, configuration, remote communication interface, remote alarm;
2. Automatic trip when deteriorated, visual alarm indication window green (normal) becomes red (fault)
3. Leakage current is small, response time fast residual depressed.
4.8/ 20 uswaveform;


订货须知

用户在产品加工定制或订货时,应详细标明产品系列、颜色、型号、级数、电压、数量。例如: D系列白色SAF-MD- -40/4- -385/100台。
Users in the product custom processing or ordering, should be marked product series, color, model, series, voltage,quantity. For example: D Series White SAF-MD- -40 / 4- -385 / 100 units.
